| Centerline Length |
28′ 0″ |
Centerline hull length |
| Beam |
9′ 8″ |
Maximum hull width |
| Bridge Clearance |
100″ |
Based on factory-installed Ultima hard top; optional outriggers and radar not included |
| Deadrise |
18° |
Hull deadrise angle |
| Draft – Hull |
18″ |
Hull draft |
| Transom Height – Centerline |
30″ |
Centerline transom height |
| Dry Weight |
6,278 LBS |
Approximate weight including boat and factory options, excluding motors, water, fuel, owner gear, and batteries |
| Maximum Weight |
9,793 LBS |
Approximate weight including boat and factory options, full fresh water, holding and fuel tanks, gear, two batteries, and largest motors |
| Fuel Capacity |
185 GAL |
Fuel capacity may vary due to US EPA Evaporative Standard requirements |
| Persons Capacity |
11 |
Maximum persons capacity |
| Total Capacity |
Yacht Certified |
Yacht Certified |
| Maximum Horsepower |
600 HP |
Maximum rated horsepower |
