Design a Blackfin Boat that’s truly a one-of-a-kind masterpiece and know there will never be someone out on the water like you.
| SPEC | US UNIT | METRIC UNIT | DESCRIPTION |
|---|---|---|---|
| LOA w/Swim Platform | 26'3" | 8.00M | Length Overall, including Swim Platform |
| LOA W/Engine | 28'6" | 8.68M | Length overall with engine |
| Beam | 9'2" | 2.79M | Width of hull at widest section including rubrail |
| Deadrise | 17° | 17° | Angle of keel measured at transom |
| Draft - Engine Up | 17" | 43CM | Depth of hull to lowest point, Outboard trimmed up |
| Draft - Engine Down | 28" | 71CM | Depth of hull to bottom of outboard, trimmed down |
| Bridge Clearance W/Hardtop | 7'9" | 2.36M | Height from water to highest point on hardtop, normal load |
| Bridge Clearance w/Upper Helm | 9'3" | 2.82M | Height from water to highest point, normal load |
| Fuel Capacity | 100GAL | 379L | Capacity of fuel tank in gallons/liters |
| Water Capacity | 15GAL | 57L | Capacity of water tank in gallons/liters |
| Waste Capacity | 11GAL | 42L | Capacity of waste tank in gallons/liters |
| Dry Weight without Engines | 4700LBS | 2132KG | Mass of boat without engine(s) and batteries, no fuel, water, waste, or gear |
| Water Ready Weight | 6300LBS | 2858KG | Mass of boat with engine, fuel, and water |
| Max Persons | Yacht Certified | TBD | Maximum Rated Persons Capacity |
| Max Power | 400HP | 373KW | Maximum horsepower for safe operation |
